Rackmount 17" LCD Console

17-Inch LCD Panel, 1U, Modular System, US English Layout

SKU: 507622 [IKVM-RC17]

Highlights

  • Integrated LCD console, keyboard & mouse
  • Manage/control PS/2 or USB computers from one keyboard, monitor and mouse (KVM module needed)
  • Standard 19-inch 1U rack drawer

Manufacturer

Intellinet Network Solutions


This console must be used in conjunction with the singular connection VGA cable set (507769) or one of the following modular KVM switches: 507776, 507844, 507882 or 507899.

  • Integrated LCD console, keyboard & mouse
  • Manage/control PS/2 or USB computers from one keyboard, monitor and mouse (KVM module needed)
  • Standard 19-inch 1U rack drawer
  • Flip-open, 17-inch LCD panel supports 1280 x 1024 resolution
  • Gain complete control with easy-to-use OSD interface
  • Adjustable - for rack cabinets with depths from 600 mm to 1000 mm (23.6 to 39.37 in.)
  • 100-key, low-profile, sturdy keyboard included
  • Ergonomic hand rest design
  • Ultra-sturdy rear bracket and extension design
  • OSD control and adjustment
  • Auto-scan automatically selects computers sequentially
  • Supports both PS/2 and USB mouse
  • Operating system independent, transparent to all applications
  • Three-Year Warranty

    Standards
  • PS/2
  • USB
  • Compatible with Windows, MAC and Unix
  • General
  • PC connections: Dependent on KVM module purchased alongside
  • Computer selection:
  • - Via buttons - Via hotkeys
  • OSD: yes
  • FCC Class B, CE, RoHS
  • Power
  • Power input (AC): approx. 100 - 240 V
  • LCD Panel
  • Active display area: 337.9 x 270.3 mm
  • Pixel pitch: 0.264 (H) x 0.264 (W)
  • Resolution: 1280*1024@60HZ
  • Brightness: 250 (Typ)
  • Contrast ratio: 1000:1 (Typ)
  • Display color: 16.7 M colors
  • User control: OSD control (auto saving)
  • Backlight unit: LED
  • MTBF: 100,000 hours
  • Keyboard
  • Ultra-thin US100 key, stand-alone removable keyboard (keyboard language format optional)
  • Microsoft Windows9、Me/NT/2000/XP、WIN7、Server2003、 WIN8、WIN10
  • Service life > 1,000,000 times
  • Mouse
  • Touch Mouse
  • 1000 point/inch(40x40/mm)
  • Service life > 1,000,000 times
  • Environmental
  • Operating temperature: 0 – 50°C (32 – 122°F)
  • Storage temperature: -20 – 60°C (-4 – 140°F)
  • Package Contents
  • 17" Rackmount Console
  • Rear bracket and extension kit
  • Power adapter
  • User manual

  • Other Part Numbers

    • EAN: 0766623507622
    • UPC: 766623507622

  • Datasheet


  • Manual
