Intellinet

Vertical Rack Mount 12-Output Power Distribution Unit (PDU)

UK BS1363A Outlets, Overload Protection, Built-in 2 m Power Cord with BS1363A Plug, On/Off Switch, 13 A, Aluminum, Black

Highlights

12-way single-phase PDU for electrical equipment, ideal for networking, telecom, security and audio/video
Overload protection with power cut at loading over 13 A
Built-in 2 m power cord with BS1363A plug

SKU: 715614

[ view high resolution images ]

Rack mount 12-way UK PDU power strip with overload protection - power up to 12 devices in your network

Plug your networking, telecom, surveillance, AV or other electronics into this 12-outlet PDU from Intellinet Network Solutions. It is compatible with standard electrical equipment and features 12 British BS1363A outlets in a durable black aluminum housing. This PDU mounts vertically in 19-inch racks. For greater safety, integrated overload protection automatically cuts power to all outlets to prevent equipment damage should an overload occur. The illuminated on/off switch provides one-touch control over all connected devices and has a protective hinged cover to prevent accidental shutdown.

12-way single-phase PDU for electrical equipment, ideal for networking, telecom, security and audio/video
Overload protection with power cut at loading over 13 A
Built-in 2 m power cord with BS1363A plug
Illuminated two-pole on/off safety switch with protective cover to prevent accidental shutdown
Sockets with increased touch protection through contact shutters
Vertical rack-mount installation
Right-angled outlet orientation
Durable aluminum construction
Grounding point to protect equipment from external electrical surges
For indoor use only
Three-year warranty

UKCA
CE
RoHS
REACH
AC input: 220.0 - 250.0 V; 50 - 60 Hz
Operating voltage: 230.0 V
Socket/outlet standard: British BS1363A
Maximum load: 3,250.00 W
Maximum load current: 13.0 A
MTBF: >100,000 hours
Dimensions (L x W x H): 62 x 768 x 47 mm
Vertical rack mount
Cable length: 2 m
Cable type: H05VV-F 3G 1.5 mm²
Net weight: 1.135 kg
Gross weight: 1.27 kg
Housing: aluminum
Vertical Rack Mount 12-Output Power Distribution Unit (PDU)
