Manhattan

USB 3.0 Type-A Active Extension Repeater Cable

USB-A Male to USB-A Female, 10 m (33 ft.), SuperSpeed USB (USB 3.2 Gen 1), 5 Gbps, Built-in Signal Booster, Black

Highlights

USB-A male to USB-A female to extend port access for easier device management or add length to a shorter cable
Supports daisy-chaining two extensions for a total distance of 20 m (65 ft.)
Strong built-in amplifier circuitry to overcome USB distance limitations and reduce signal loss

SKU: 153751

[ view high resolution images ]

USB 3.0 Extension Cable - go beyond the length limit of standard USB cables

Standard USB 3.0 cables have a length limit of 3 m (10 ft.), that is as far as passive USB cables will carry the signal. The Manhattan USB 3.0 Type-A Active Extension Repeater Cable lets you overcome that classic limitation to connect a USB device, like a USB printer or a USB surveillance webcam, at further distances.

Active signal boost

This active USB 3.0 extension cable beats distance restrictions by incorporating bus-powered active circuitry, which can add another 10 m (33 ft.) to your existing connection. If you want to go beyond that, you can cascade two of these extenders for a total USB extension of 20 m (65 ft.).

Complete USB 3.0 features

With one USB-A male connector and one USB-A female connector, this USB extension cord extends port access for easier device management or adds length to a shorter cable. Sync music, photos or data with fast speeds up to 5 Gbps. The double shielding (aluminum foil and braid) and corrosion-resistant contacts provide maximum signal integrity.

USB-A male to USB-A female to extend port access for easier device management or add length to a shorter cable
Supports daisy-chaining two extensions for a total distance of 20 m (65 ft.)
Strong built-in amplifier circuitry to overcome USB distance limitations and reduce signal loss
Transfer speeds up to 5 Gbps
Foil and braid double shielding to reduce EMI and other interference sources
Corrosion-resistant contacts
Heavy-duty strain relief
Supports current up to 150 mA
Plug-and-play installation; Windows®, macOS®, Linux® and Chrome OS™ compatible
Bus powered: no external power supply needed
Works with standard USB 3.0 cables; backward compatible with USB 2.0 and USB 1.1
Three-year warranty

UL
CE
FCC
RoHS
REACH
UKCA
One USB-A 9-pin male
One USB-A 9-pin female
28/24 AWG
Double shielding: aluminum foil and braid
Nickel-plated contacts
Wire: copper-clad aluminum (CCA)
Jacket OD: 4.5 mm (0.18 in.)
Molded PVC boot
Length: 10 m (33 ft.)
Net weight: 270 g (0.6 lbs.)
Gross weight: 277 g (0.61 lbs.)
Withstanding voltage: 300.0 V DC 10 ms
Insulation resistance: 5 MΩ
Contact resistance: 2 Ω
Supported current: 150 mA
Operation temperature: 0 - 40°C (32 - 104°F)
Storage temperature: -20 - 60°C (-4 - 140°F)
Humidity (noncondensing): 0 - 96%
USB 3.2 Gen 1 Type-A Active Extension Repeater Cable (USB A Male to Female)
#153775 - USB 2.0 Active Extension Cable, A-Male/A-Female, 5 m
#153782 - USB 2.0 Active Extension Cable, A-Male/A-Female, 10 m
#153799 - USB 2.0 Active Extension Cable, A-Male/A-Female, 15 m, optional external power supply
#153805 - USB 2.0 Active Device Cable, A-Male/B-Male, 15 m, optional external power supply
#153737 - USB 3.0 Active Extension Cable, A-Male/A-Female, 5 m
#153744 - USB 3.0 Active Extension Cable, A-Male/A-Female, 7.5 m
#153751 - USB 3.0 Active Extension Cable, A-Male/A-Female, 10 m
#153768 - USB 3.0 Active Extension Cable, 15 m, A-Male/A-Female, optional external power supply
